Lexicon PCM96 Effects Processor (Used)

Front End Audio acquires previously owned gear through our Buy-Back program. You can purchase used gear at a great price but there are no manufacturer warranties with these items. These items have been inspected and/or tested by our staff to make sure each one is in working condition and comes with our commitment to service. This Lexicon PCM96 Effects Processor looks and functions perfectly. It includes everything as if you were to buy it new.

The Lexicon PCM96 Effects Processor is an artful blend of heritage and innovation, designed to deliver new and legendary Lexicon reverbs, delays and modulation effects straight into your DAW. The Lexicon PCM96 Effects Processor is designed for the modern studio, offering 28 new and legendary Lexicon reverbs, delays and modulation effects. An artful blend of heritage and innovation, the PCM96 Stereo Reverb/Effects Processor delivers 28 new and legendary Lexicon reverbs, delays and modulation effects. Appearing for the first time are new Room and Hall algorithms, plus an assortment of new mono reverbs and effects. With decades of legacy products to pull from, the PCM96 also includes the finest collection of factory presets available in a stereo processor – over 1200 and growing – including some recognizable classics from our immense library of sounds.

The PCM96 gives new capabilities to our traditional reverbs by adding multimode filters at several spots in the audio flow. This allows more exact shaping of the reverb while still maintaining the distinctive Lexicon sound. All reverbs also have an "Infinite" switch that allows the reverb to run forever, a useful feature for creating unusual backgrounds and sound effects. Lexicon's new Room algorithm provides a more flexible alternative to convolution type reverbs. Reflection patterns can be easily selected, scaled and equalized – all while simultaneously passing audio. They can be instantly reversed or combined with a traditional reverb to extend the decay or bring a stronger sense of “liveness” to the space. With two channels XLR analog, two channels XLR AES/EBU digital I/O, and MIDI, the PCM96 easily fits into a variety of recording and live sound environments. In any application, the PCM96 delivers the versatility and sound that is unmistakably Lexicon.

Lexicon PCM96 Effects Processor Features

• New and legendary Lexicon reverbs, delays, and modulation effects
• Lexicon's new Room algorithm, used to generate a vast array of room-related effects for music and post
• Over 1200 factory presets, including recognizable classics from Lexicon's immense library of sounds
• Seamless automation and control via Ethernet or FireWire
• Hardware Plug-In capability inside Mac VST® and Audio
• Units production software
• 32-bit Floating point processing
• Sample rates up to 96kHz
• Two channels XLR analog I/O
• Two channels XLR digital AES/EBU I/O
• External BNC Wordclock
• MIDI in, out, and thru
• 768 User presets
• Compact Flash for additional storage

Lexicon PCM96 Effects Processor Specifications

• Analog Audio Inputs:
  • Connectors: Two, Female XLR
  • Impedance: 20k Ohm, balanced
  • Input Level:
    • +4dBu Mode: +20dBu max
    • -10dBu Mode: +8.2dBu max
    • Type IV Mode: +26dBu max
• Analog Audio Output:
  • Connectors: Two, Male XLR
  • Impedance: 30 Ohm, electronically balanced
  • Output Level: +20dBu
• Digital Audio I/O:
  • Connectors: One Female XLR Input, One Male XLR Output
  • Two FireWire Ports: Format AES/EBU balanced FireWire (400Mb)
  • Conversion: 24-bit A/D; 24-bit D/A
  • Sample Rates: 44.1kHz, 48kHz, 88.2kHz, 96kHz
  • Accuracy: Within +/-50ppm
  • Lock Range: +/-2% of nominal
• Audio Performance:
  • Freq Response @96KHz: 20Hz to 20kHz, +/-0.25dB, 20kHz to 40kHz, +0/-3dB
  • THD: <.002%, 20Hz to 20kHz @ +4dBu
  • Dynamic Range: >112dB unweighted, 115dB A-weighted
  • Crosstalk @ 1kHz: <-90dB, 20Hz to 20kHz @ +20dBu input
  • Internal Audio DSP: 32/64-bit floating point
• Synchronization:
  • TTL Word Clock Input: 75 Ohm, BNC
  • Control Interface:
  • MIDI: In/Out/Thru
  • Memory Card: Compact Flash Type I
• Environment:
  • Operating: 15° to 35° C
  • Storage: -30° to 70° C
  • Humidity: 75% relative humidity max
• General:
  • Rack Units: 1U
  • Dimensions: (W x H x D) 19.0" x 1.75" x 12.5", 483mm x 44.5mm x 317.5mm
  • Weight: 8.65 lbs
  • Power Consumption: <20W

Lexicon PCM96 Effects Processor Includes

• Lexicon PCM96 Effects Processor
• Power Cable
• Ethernet Cable
• User Manual
• Original Box
