Furman M-8S Power Conditioner

(No reviews yet) Write a Review
Product Code: 9999-16404
$279.00
UPC:
654061041078
Availability: Usually Ships in 24 Hours

Furman M-8S Power Conditioner

The Furman M-8S Power Conditioner is the perfect low-cost AC power solution for any rack mount system. While preventing excessive inrush currents with power sequencing and noise filtering and reducing RF and electromagnetic interference, the M-8S ensures the safety of your equipment.

The Furman M-8S Power Conditioner is a rack-mountable AC power solution for your system. Install the Furman M-8S Power Conditioner in your rack, and the eight outlets in the rear panel will power up in sequence and protect all your equipment up to a 15-Amp load.

The Furman M-8S Power Conditioner is the perfect low-cost AC power solution for any rack mount system where power sequencing is desired.

Install the Furman M-8S Power Conditioner in to the top slot of your rack, and the six delayed outlets in the rear panel will power up sequentially and protect all your equipment up to a 15-amp load.

Includes 3 delayed outlet banks - each with 2 outlets - plus 2 unswitched outlets.

Furman M-8S Power Conditioner Features

  • Standard level AC protection and filtering
  • Six sequenced rear panel outlets (in 3 groups), two unswitched rear panel outlets, and one front panel unswitched outlet
  • Momentary and Maintained sequencing via rear panel terminal block or front panel switch (momentary only)
  • All settings and configurations available on rear panel
  • Noise filtering to reduce radio frequency and electromagnetic interference
  • Surge protection feature ensures equipment stays safe
  • Rear outlets have been spaced to accommodate even the bulkiest of wall warts and adapters
  • 15 Amp rating with circuit breaker

Furman M-8S Power Conditioner Specifications

  • Manufacturer: Furman
  • Product: M-8S Power Conditioner
  • Maximum Output Current: 15 Amps, 120 VAC (Thermal breaker)
  • Line Cord: 14AWGx3, 10 feet, black, fixed, NEMA 5-15P plug
  • Standard Level AC Surge Protection: Merit Class (sacrificial)
  • Spike Protection Mode: Line to neutral, zero ground leakage
  • Max Continuous Operating Voltage: 130V RMS
  • Max Clamp Voltage: 500 Volts Peak
  • Peak Impulse Current: 12,000 Amps
  • Energy Rating: 225 Joules
  • AC Filtering: Standard level Pi LCR Filter
  • Noise Attenuation: >26dB, 100 KHz to 1 MHz
  • Operating Temperature Range: 5C (40F) to 40C (105F) degrees
  • Humidity Range: <90% rH (Relative Humidity)
  • Rocker Switch: Front panel, Sequence (ON, OFF)
  • Thermal Circuit Breaker: Front panel, push to reset
  • Front Panel Indicators: Delay 1, Delay 2, Delay 3, Power, Protection OK
  • Rear Panel DIP Switches: 12V Mode On/Off, GND Mode On, Momentary/Maintained
  • Potentiometer: Rear panel, time calibration fine tune delay adjust
  • Remote Terminal: +5-30VDC In, 12VDC (12mA) Out
  • Dimensions: (L x D x H) 19" x 8.75" x 1.75" ANSI 1RU
  • Weight: 7 lbs.
  • Power Consumption: 5 Watts
  • Safety Agency: C/CSA/US

Furman M-8S Power Conditioner Includes

  • M-8S Power Conditioner
  • 3 Years Warranty

Furman M-8S Power Conditioner Downloads
